Electrical Input voltage range: AC110V-240V 50/60Hz Max Power Consumption: 800W max Light Source: 600W White LED engine CCT: 6500K CRI: >95 LED average life: +20,000H
Optical systems Motorized zoom range: 5°-50°
Motorized focusing system Multiple speed strobe effect：0-25Hz; 1-13times/snd Dimmer: 0-100% linear control CTO color adjustable from 2500K-7000K
Prism/Colors/Gobos 4 facet circular prismand 6-facet linear prism Color wheel: 8+ open Static gobowheel: 11+ open Rotating gobo wheel: 7+ open With electronic frost filter Iris: Fast iris diaphragm with adjustable dynamic effects, 5% to 100% open Frost: motorized frost filter Independent CMY color mixing system
P/T Movement Pan: 540° Tilt: 270° Pan/Tilt position out-of-step auto-correction Pan/Tilt: 16 bit precision scanning Fixed lock: horizontal/vertical lock |
| Control Control channel: 24CH Control protocol: Standard DMX512 protocol+ RDM protocol Channel Mode: Stand-alone mode, voice-activated, Master/Slave mode, DMX512 control Control panel: LCD displaywith power-off setting allows operation of LCD interface without connecting toa power source Data Connection: 3pin/5pin DMX XLR Power Connection: True1 IP rated Input/Output IntelligentHeat Dissipation: Utilizing wind direction guidance and temperature smart monitoringtechnology, it automatically drives cooling fans in different parts of theluminaire based on temperature variations across various location, effectivelycooling the luminaire components
Housing IP rating: IP20 Material: Plastic and rubber material cover Dimension: 360x270x680mm Net weight: 23.5kgs Gross weight: 25.5kgs
Accessories Power cord: including DMX cable: including Safety cable: including Folding clamp: including 2in1 flight case: optional |
|
